AM1000Wall-Mounted Decentralised Ventilation Unit

The AM 1000 from Airmaster is a high-capacity wall-mounted decentralised ventilation unit designed for large rooms with high occupancy, such as classrooms and offices. It delivers powerful airflow while maintaining low noise levels and high energy efficiency, making it ideal for demanding indoor environments.

Key Features

• High airflow capacity – designed for spaces with high ventilation demand (e.g. classrooms)

• Decentralised system – no extensive ductwork required

• Integrated heat recovery – over 80% efficiency for reduced energy loss

• Adaptive Airflow™ technology – automatically adjusts air distribution to prevent draughts

• Active noise attenuation – built-in system reduces low-frequency noise using counter-noise technology

• Modular design – delivered in sections for easier transport and installation

Applications

Ideal for larger, high-occupancy spaces:

• Classrooms

• Offices

• Meeting rooms

• Training and education environments

Performance & Technical Highlights

• Airflow capacity:

o Up to approx. 950–1000 m³/h

• Airflow range:

o ~264 – 962 m³/h depending on configuration

• Noise levels:

o Around 30 dB(A) at typical operation

• Heat recovery efficiency:

o Typically 75–80%+

• Specific Fan Power (SFP):

o ~700 J/m³ (energy efficient operation)

Design & Installation

• Wall-mounted unit with multiple configuration options:

o Horizontal, vertical, and side duct variants

• Flexible duct connections (top, rear, side combinations available)

• Modular construction simplifies installation and handling

• Compatible with:

o Wall-mounted or ducted intake/extract configurations

Optional Cooling Module

• RC 1000 cooling module available

• Provides cooling capacity up to ~7 kW

• Enables full indoor climate control (ventilation + cooling)

Efficiency & Benefits

• High-performance ventilation for large spaces

• Energy-efficient heat recovery reduces operating costs

• Demand-controlled airflow improves comfort and efficiency

• Low noise design ideal for learning and working environments

• Adaptive airflow prevents draughts across varying conditions
