AM 800Wall-Mounted Ventilation Unit

The AM 800 is a high-capacity decentralised ventilation unit with heat recovery, designed for larger rooms such as classrooms, offices and meeting spaces.

It provides efficient, low-noise ventilation with intelligent demand control, ensuring a healthy indoor climate while minimising energy consumption.

Key Features

• Decentralised ventilation with heat recovery

• Energy-efficient operation

• Low noise levels

• Demand-controlled ventilation (CO₂-based)

• Flexible installation options

• Optional heating and cooling modules

• BMS compatibility

Performance

• Airflow: up to ~700–750 m³/h

• Sound level: from ~30–35 dB(A)

• Heat recovery: high-efficiency counterflow exchanger

• Filters: up to ePM1 80%

• Power supply: 230V

Installation & Variants

• Horizontal and vertical configurations available

• Multiple inlet and outlet positions (top, rear, bottom)

• Options for ducted or non-ducted setups

• Suitable for wall-mounted or integrated installation

Applications

• Classrooms and schools

• Offices

• Meeting rooms

• Commercial spaces

Controls & Options

• CO₂-based demand control

• Heating and cooling modules (e.g. CC 800)

• Airlinq® control system

• BMS integration (BACnet, Modbus, KNX)
